Dimensions
|
44mm (H) x 442mm (W) x 220mm (D)
|
88mm (H) x 442mm (W) x 220mm (D)
|
221 mm (H) x 442 mm (W) x 224 mm (D)
|
722 mm (H) x 497 mm (W) x 295 mm (D)
|
757 mm (H) x 497 mm (W) x 295 mm (D)
|
800mm (H) x 496mm (W) x 295mm (D)
|
|
Switch capacity
|
Packet: 7.2 Gbit/s and TDM: 21.25 Gbit/s (higher order), 5 Gbit/s (lower order)
|
Packet: 64 Gbit/s ,TDM: 20 Gbit/s (higher order)
|
Packet: 560 Gbit/s, TDM: 280 Gbit/s (higher order)
|
Packet: 160 Gbit/s and TDM: 200 Gbit/s (higher order), 20 Gbit/s (lower order)
|
Packet: 160 Gbit/s and TDM: 360 Gbit/s (higher order), 80 Gbit/s (lower order)
|
Packet: 320 Gbit/s and TDM: 360 Gbit/s (higher order), 40 Gbit/s (lower order), OTN: 560Gbit/s
|
|
Service slots
|
3 slots
|
8 slots
|
15 slots
|
15 slots for processing boards and 16 slots for interface boards
|
22 slots for processing boards and 8 slots for interface boards
|
32 slots, 16 slots for interface boards and 16 slots for processing boards with same bandwidth per slot
|
|
Power Supply
|
48V DC/ -60V DC, 220V AC/110V AC
|
-48 V DC/-60 V DC
|
-48 V DC/-60 V DC
|
-48V DC/ -60V DC; 110/220V AC (External module)
|
-48V DC/-60V DC; 110V AC/220V AC (External module)
|
-48V DC/-60V DC
|
